Waitangi Golf Club
Northland · 19 greens mapped
Read these greens →
The greens here
19 greens at Waitangi have been mapped from the national LiDAR survey — 7,231 m² of putting surface altogether, with a median green of 365 m². That is within a few percent of the national median of 397 m² — typical for New Zealand.
- Steepest green: hole 9, averaging 3.5% and falling south.
- Flattest green: hole 4, at 0.6%.
- Most internal fall: hole 17, 1.21 m between its low and high point.
- Largest green: hole 17, 535 m².
Every green
| Green | Size | Fall | Avg grade | Runs off to the |
|---|---|---|---|---|
| Hole 1 | 293 m² | 0.45 m | 2.1% | north |
| Hole 2 | 377 m² | 0.49 m | 1.6% | south-west |
| Hole 3 | 355 m² | 0.45 m | 1.8% | north-east |
| Hole 4 | 257 m² | 0.15 m | 0.6% | south |
| Hole 5 | 403 m² | 0.31 m | 0.9% | east |
| Hole 6 | 340 m² | 0.85 m | 3.4% | south-west |
| Hole 7 | 354 m² | 0.55 m | 2.4% | south-west |
| Hole 8 | 434 m² | 0.75 m | 2.3% | south-east |
| Hole 9 | 470 m² | 0.97 m | 3.5% | south |
| Hole 10 | 418 m² | 0.83 m | 2.7% | north-east |
| Hole 11 | 357 m² | 0.49 m | 2.6% | west |
| Hole 12 | 345 m² | 0.81 m | 3.3% | north-east |
| Hole 13 | 340 m² | 0.73 m | 2.9% | east |
| Hole 14 | 365 m² | 0.24 m | 0.8% | north |
| Hole 15 | 482 m² | 0.99 m | 2.7% | north-east |
| Hole 16 | 325 m² | 0.30 m | 1.1% | north-east |
| Hole 17 | 535 m² | 1.21 m | 2.4% | south-west |
| Hole 18 | 390 m² | 0.81 m | 2.7% | south-west |
| Green A | 393 m² | 1.08 m | 3.5% | east |
“Fall” is the height difference between the lowest and highest point of the putting surface. “Avg grade” is the best-fit plane across it — a green can average 2% and still have a shelf on it, which is what the app shows and a table cannot.
Where these numbers come from
Heights come from Land Information New Zealand’s 1 m LiDAR elevation survey (Northland, 2018-2020), published openly under CC BY 4.0. Green outlines and hole numbers come from OpenStreetMap under the Open Database Licence. Slope uncertainty on this course works out at ±0.15%.
Slope is measured. Break is modelled — the read in the app is a physics simulation of a ball rolling over the measured surface, and it knows nothing about grain or moisture. The survey predates any green rebuilt since 2020. More about how this is made.
